Propeller Hub Kit 707 - Honda, Suzuki 200HP & Above

90-300+hp ENGINES WITH A 4.75" GEARCASE

MASTERGUARD 500 Series Installation Kits
500 Series Installation Kits
Lifetime Warranty For
Engines Under 200hp

MASTERGUARD 700 Series Installation Kits
Engineered For Big HP
Lifetime Warranty For
Engines 200+hp

500 & 700 Series Installation Kits
Premium corrosion resistant brass splines. Eliminate hub system vibration & chatter. Reduce gear shock & engine/drive damage. Reduce prop replacement cost by up to 50%.

500 & 700 Series MasterGuard Installation Kits & Corresponding Prop Housings are Compatible with, and Upgrade Competitors’ Hub & Prop Systems. Interchangeable with Mercury® Flo-Torq II®, Michigan Wheel® XHS®, Solas® Rubex™ hub kit systems.
NOTE: Not applicable with Turning Point’s 10, 20 and 200 Hub Kit series.

* Motors 200HP and above must use series 700 Hub Kits. Failure to use will void warranty.
Engine Brand - 15 Spline Prop Shaft	Kit	Part #
EVINRUDE® & JOHNSON®: V4 with V6 large gearcase: 100hp commercial, 120hp ('85),130hp ('95-'96), 140hp ('85), Pleasure ('95+): 115hp, 130hp / H.O. (includes E-TEC H.O.): (25" shaft) 90, 115, 135, 150, 200, 225, 250hp E-TEC (includes pontoon series - not for E-TEC G2): (25" shaft) 90hp, 115hp, 130hp ('09-'10), 135hp to 300hp / V6: 135hp to 250hp / V8: 250hp to 300hp	502	203502
EVINRUDE® E-TEC® G2™: G2 Series Only: 150 to 300hp	511	203511
HONDA®: Note: Use 707 Super Duty Kit for 200+hp Engines. BF115D, BF135, BF150, BF200 ('02-'12), BF225 ('02-'12)	507 707*	203507 203707
HONDA®: Note: Use 708 Super Duty Kit for 200+hp Engines. BF200A ('13+), BF225A ('13+), BF250A ('12+)	708*	203708
JOHNSON®: (use Express Mach3 OS series props only) 4 stroke: 200hp, 225hp	707*	203707
MERCURY® & MARINER®: Note1: Use 701 Super Duty Kit for 200+hp Engines. Note2: 115hp ProXS CT Only; For ProXS & Verado w/ 1.25” prop shaft, use Mercury Solid Hub kit with the Turning Point Prop. EFI CT / SeaPro : 90 to150hp / V6 & I6: 135 to 300hp / Verado 135 to 300hp(not HD) / OptiMax: 150, 200, 250hp	501 701*	203501 203701
MERCRUISER®: Note1: Use 701 Super Duty Kit for 200+hp Engines. Note2: If propeller strikes trim tab, replace with Mercury part #822777A1 Alpha One and Bravo One ('83+)	501 701*	203501 203701
OMC®: Cobra 800: 3.0 to 7.5L / King Cobra: 454, 502 / Sea Drive: 2.0 to 4.0L	502	203502
SUZUKI®: Note: Use 707 Super Duty Kit for 200+hp Engines. DT 2 stroke: 150hp to 225hp	507 707*	203507 203707
SUZUKI®: Note: Use 707 Super Duty Kit for 200+hp Engines. (use Express Mach3 OS series props only) DF 4 stroke: 150 to 300hp	507 707	203507 203707
TOHATSU®: Note: Use 708 Super Duty Kit for 200+hp Engines. BFT115, BFT150, BFT200, BFT225, BFT250	508 708*	203508 203708
VOLVO®: Penta SX & OMC SX Cobra: (19 spline) ('94+): 3.0 to 8.2L. Not available for Volvo DuoProp or Aquamatic drives.	504	203504
VOLVO®: Penta AQ: (17 spline) (use 4 blade props only) 200, 250, 270, 280, 290	510	203510
YAMAHA®: Note1: Use 705 Super Duty Kit for 200+hp Engines. Note2: If Express Mach3 OS Prop strikes trim tab, replace with	505	203505
YAMAHA®: part #6E5-45371-10-00. 2 and 4 stroke: 150 to 250hp / F300 (V6 only ‘09+) / Sterndrives 3.0 to 7.4L	705*	203705
YAMAHA®: F350	715*	203715

Stainless Steel Propellers
EXPRESS PROP OPTIONS
90-300+hp

3-Blade (LH) (RH) 15”, 17”, 19”, 21”, 23” pitch

4-Blade (LH) (RH) 11”, 13”, 15”, 17”, 19”, 21”, 23” pitch

Aluminium Propellers
HUSTLER PROP OPTIONS
90-300+hp

3-Blade (RH) 15”, 17”, 19”, 21”, 23” pitch

4-Blade (LH) (RH) 15”, 17”, 19”, 21” pitch

*Note: To find the correct Installation Kit locate the HP, gearcase size, and prop shaft spline count of your outboard or sterndrive.
